The evolution of The Patch

During
the ITD project, our Max patch has gone through some radical changes. It has
evolved from a simple input output patch to a full grown patch containing
several different functionalities.

Having
arrived at the end of the project, we thought it would be interesting to
discuss this progression, as well as evaluate the use of Max. That is what this
post will be about.



The first
steps

Having
had no prior experience with Max as a programming tool, I started with a simple
patch for our concept in the first cycle – the sensor chair.

As
you can see in the image below, the patch is fairly straightforward an contains
only a small number of objects.

The
most challenging part in building this patch was to make an “if/else-statement”
using the visual programming language of Max instead of the cold logics of a
language based programming language.



Towards
maturity

As
we progressed towards a final prototype, the Max patches also grew more
complex. At first, we still transferred messages through one computer. We had
two separate patches, one for each concept, and we connected the prototypes to
two separate ports of one Arduino. An example of these patches can be seen
below. Two drawbacks of these patches are that 1) they are not generic and
therefore had to be synchronized all the time and 2) the messages could still
not be sent over the wireless network, which was our ultimate goal.

Notice
that this patch contains a Phidget interface kit and a Maxuino interface. This
last element was used to communicate with the Arduino in the concept. This
provided us with the handles to use the pulse width modulation of the Arduino
and still be able to use Max for the programming.



However,
we still had to incorporate sending and receiving messages over the wireless
network. This was done in the next iteration cycle, of which the patch is shown
below.

Apart
from the addition of message transfer, the Phidget interface kit was removed.
Instead, we used an Arduino shield, which was made by Rob Luxen. This enabled
us to make the prototype smaller and made it possible to use just the Maxuino
interface to collect sensor data and send both digital and analog outputs to
the Arduino board.



The fully evolved
Patch

Since
this patch is somewhat chaotic to someone who is not familiar with the patch, I
started cleaning up the patch. First by using sub patches which I saved in
separate files and then by making patchers in the main patch. The latter
approach proved to be more practical, because the patchers were accessible from
the main patch straight away and instead of having to open a separate file.
Apart from that, the changes made to the patchers are incorporated straight
away, whereas changing elements in a separate sub patch file required
restarting the main patch for the changes to take effect.

To
make the patch more structured I made the division in the patch more clear by
separating the different parts of the patch that are related to a certain
functionality using panels. The result of this iteration can be seen below.

Evaluation

This
patch is the final result of half a year of working with Max/MSP a programming
tool. Given the fact that I had no prior experience with Max I can say that I
have come a long way in learning how to use the language.

In
the beginning I sometimes had no idea where to start in building a
functionality. At the end of the project, on the other hand, I had arrived at a
point where most of the times I could directly pinpoint the cause of a certain
malfunction of bug in the patch. At last I also knew in most cases which
construction of Max-objects I needed to solve these problems. Concluding, I can
safely say that getting familiar with Max took me quite some time, but this
paid off in the end: I have learned a new programming language which I think
can be a benefit in building interactive prototypes.

However,
I think that for making a stable piece of intelligence for a product, it is not
the most appropriate tool. This is mostly due the fact that, when building a
patch in Max, you tend to build one problem fix upon another. I think this is mostly due to the iterative style of programming which Max supports so very well. However this leads to
either new problems or an ever more complex patch. In order to solve this, the
best thing is to start again from scratch, but then it is not always simple to
incorporate all the intended functionalities in a clean way straight away. On the other, language based programming,
on the other hand, makes it easier to re-use code fragments.

In
our case it did not matter though; the prototype has worked throughout the
exhibition without becoming instable.



Tim
Overkamp – programmer Generation Y1

`The Happy End`-Movie

And-this is the last post from toolkit group.We hope you enjoyed with following our works during the semester.

Last words are from our movie and here is the link:

http://www.youtube.com/watch?v=74OS2v9Htyw

Enjoy!
Toolkit group (only one)







Final exhibition

Here is the final movie, which concludes concept, process, prototype and exhibition.

[object:flash:http://www.youtube.com/v/qkqKjWhxy3Y?fs=1&hl=nl_NL width:480 height:390]

 We have enjoyed a great semester with nice teamwork. Thanks for your attention.





Final prototype

The following is the picture of final prototype.





Exhibition and final movie

Hello there,



The project has come to an end. The exhibition was succesfull and our team was very relieved it all came together.

Our final presentation movie explains the concept:

YouTube Preview Image



To show you some impressions of the exhibition, check out this movie:

YouTube Preview Image



These photo’s show the final prototype as we demonstrated it at the exhibition. It was very cool to see so many people playing with it. Thanks for the feedback everybody.



Final prototype



The studio set up



The visitors











We hope you all enjoyed the project, the exhibition, our blog and our prototype. That’s it for us this year. Happy hollidays!



Regards,

Team Generation Y1



Exhibition and final movie

Hello there,



The project has come to an end. The exhibition was succesfull and our team was very relieved it all came together.

Our final presentation movie explains the concept:

YouTube Preview Image



To show you some impressions of the exhibition, check out this movie:

YouTube Preview Image



These photo’s show the final prototype as we demonstrated it at the exhibition. It was very cool to see so many people playing with it. Thanks for the feedback everybody.



Final prototype



The studio set up



The visitors











We hope you all enjoyed the project, the exhibition, our blog and our prototype. That’s it for us this year. Happy hollidays!



Regards,

Team Generation Y1



Cashpoint 3 – Final movie

 We hereby present our final movie, thanks for following our blog!

YouTube Preview Image

‘The Happy End’ – Photos




Lastly, the photos from our prototype:










last times and the exhibition day



Yes, the last couple of weeks were the most tiring stressfull and busy weeks. We were dealing with the last minute problems,finalizing the prototype,visuals to explain our concept, blogging to keep you updated,report to tell our whole process..

Here you see some snapshots from those moments that we feel a bit (!) freaked out 🙂





And finally- the exhibition day we set up a  ‘mysterious’ exhibition space to call people come and explore the world of electronics…







It was a fantastic atmosphere to walk around all the studios and enter a different context each time and try out different prototypes with enjoyable concepts…

In the end of the day, we were tired but happy and satisfied with all the reactions we got from the guests…It was nice experience to share our 5 months effort with the people… And more importantly, to see them playing with the toolkit with a curiosity and smile on their face…





PreVIEWWWW



Tegg shell is ready with the paint..

Movie making is in process.
We will print the brochures and poster on  Tuesday.


Finger crossed for u all~
See you on Wednesday.
